There are as many mixer designs as the variety of industrially homogenous materials. More than 100 different mixer types are produced for homogenizing only viscous materials.

Among them, the homogenizer activity, which quickly and easily homogenizes liquids in the low viscosity range (< 250mPa*s), is one of the best proven mixer types. The homogenizer runs at very high speeds and can be used for suspension, emulsification and gassing applications as well as for homogenization of liquids. This product runs at very high speeds as a traveling mixer and can be used for suspension, emulsification and degassing applications as well as homogenization of liquids.

The design and production of homogenizers are always carried out exclusively by the customer.

Take advantage of our experience. Call us for your customized solutions!

Mixing and laboratory testing can be done at Isımsan's own technical center.

Applications:

Foods, cosmetics, chemicals, pharmaceuticals, etc.

Design features

The drive shaft of the homogenizer can be single or double depending on the choice, up and down. This allows the use of 2 mixing vehicles, which operate independently of each other in two opposite directions. Speeds of 4.000 rpm per drive are produced. Performance is doubled with 2 mixers.

Design

Body size : up to 300 liters
Body shape : cylindrical
Base shape : flat, dished
Material : stainless steel
Surface : brushed, polished, mirror polished
Mixer shaft : single shaft
Rpm : 1.000 - 4.000
Blades : different types possible

Optional parts

  • Sampling valves
  • Mechanical seals
  • Heating and cooling jacket
  • Mixer body produced as single or double walled (process dependent) model
  • Various automation sensors
  • Eyeglass with lighting
  • Support frame and platform
  • Automatic cleaning system (CIP)
  • Speed control
  • Remote Control
  • etc.

PRODUCT OFFER REQUEST FORM

Online Product Inquiry For your individual product solution we gladly take a first draft including price calculation. You will receive this within a few days. Please use our online product inquiry or contact us directly.

Isımsan - We are there for you

Isımsan manufactures plants individually and according to the following International directives and regulations:

  • CE 2006/42/EG (Machinery Directive)
  • CE 2014/29/EU (Pressure vessel directive)
  • CE 2014/68/EU (Pressure vessel directive)
  • ATEX product line 2014/34/EU
  • EHEDG (European Hygienic Engineering and Design Group)
  • GMP (Good Manufactuning Practise)
  • FDA (U.S. Food & Drug Administration)
  • EAC (EurAsia Conformity)

Further guidelines can be considered after consultation.
Isımsan is certified in terms of quality management (ISO 9001), environmental standards (ISO 14001), welding technology and supervision (ISO 3834 & 14731) and control technology (2006/42/EC).
